High quality Stepper motor 12V

 Nhà sản xuất : SeeedStudio

 Tình trạng        : Còn hàng



Mã Sản Phẩm : MOT106A3B


Giá : 209,000 VND (đã có VAT)
Qty :

 Mainly used in Air Conditioner Louver , Small Cooling/Heating Fan etc., Stable and all technic parameters are qualified for national electronic standard of SJ/T10689-95

Specifications
  • Rated voltage  12VDC
  • Number of Pole  4
  • Speed Variation Ratio  1/64
  • Stride Angle  5.625° /64
  • DC resistance  200Ω±7%(25°C)
  • Idle In-traction  Frequency >600Hz
  • Idle Out-traction  Frequency >1000Hz
  • In-traction Torque  >34.3mN.m(120Hz)
  • Self-positioning Tor >34.3mN.m
  • insulated resistance >10MΩ(500V)
  • insulated electricity power 600VAC/1mA/1s
  • Insulation grade A
  • Rise in Temperature  <40K(120Hz)
  • Noise  <40dB(120Hz,No load,10cm)
